60W LED Mini Fresnel Spot Theatre Museum Light
60W LED Mini Fresnel Spot Theatre Museum Light 60W LED Mini Fresnel Spot Theatre Museum Light 60W LED Mini Fresnel Spot Theatre Museum Light 60W LED Mini Fresnel Spot Theatre Museum Light

60W LED Mini Fresnel Spot Theatre Museum Light

Product ID : Mini Fresnel60 LED VW
Product Tags :
Product Attributes :

60W LED Mini Fresnel Spot Theatre Museum Light

Product Description

Fresnel60 VW LED

Product Name:  60W LED Mini Fresnel Spot Theatre Light


Technical Specification


Optical
Light Source: 60W Cool White and Warm White 2-in-1 LED
Life expectancy: Rated at 50,000 hrs.
Light Number:1 PCS
Lens: Pro Glass Fresnel
Beam angle: 15 - 35 degree Zoom (By manul)
CT: 3200 K - 5600K adjustable by control panel or DMX controller
CRI: > 95
PWM frequency: 20,000 Hz

Dynamic Effects:
Dimmer:Electronic Dimming: 0 - 100%
Dimmer Modes:Linear Dimming
Flicker Free:Yes, Good for HD Vedio, Camera, TV studio,Theatre, Stage … and so on
Shutter/Strobe: Electronic, Rate 0 to 20 Hz
Standalone Color Mixing:Yes
Built-in Automated Programs: Yes

Electrical
Power Draw Total: 80W Max (All LED's @ Full On)
Multi-voltage operation:AC 100-240V, 50/60Hz
Power Daisy chain: 8 fixtures (120V); 16 fixtures (230V)
Cooling:  Silent, No fan. Air convetion cooling with smart thermal sensor

Connection:
DMX: 3-Pin XLR In/Out (5-pin for option)
Power: Power Cord with In/Out connectors (linking connetors)

Control
Control protocol: DMX-512
DMX Channels: 3/10 channels
Stand Alone: Auto,  Master/Slave
Control Panel Display: LED Display
RDM:Yes

Construction / Physical:
Housing: Aluminum, Black
Dimensions (LxWxH):  310x 179 x 130 mm
Weight: 3 kg.
IP Rating: IP20



]
